Hey guys! Let's dive into a geometry problem where we need to find the angles of a quadrilateral. We'll explore two scenarios where the angles are proportional to different sets of numbers. We'll also figure out whether the resulting quadrilateral is convex or non-convex. Buckle up, it's gonna be a fun ride!

Problem Statement

We are given that the angles of a quadrilateral are proportional to the numbers:

a) 1, 2, 3, 4 b) 1, 2, 2, 13

Our mission, should we choose to accept it, is to:

  1. Determine the measure of each angle in both scenarios.
  2. Classify the quadrilateral as either convex or non-convex in each case.

Key Concepts

Before we jump into the solutions, let's refresh some fundamental geometric concepts that will be our trusty tools in this endeavor.

Quadrilaterals

A quadrilateral, at its heart, is a polygon with four sides, four angles, and four vertices. It's a fundamental shape in geometry, and understanding its properties is key to tackling problems like this. The sum of the interior angles in any quadrilateral is always 360 degrees. This is a crucial piece of information that we'll use extensively.

Proportionality

When we say that the angles are proportional to a set of numbers, it means that the ratio between the angles is the same as the ratio between the numbers. For example, if the angles are proportional to 1, 2, and 3, it means that one angle is twice the size of the first, and the third angle is three times the size of the first. We can express this mathematically by introducing a constant of proportionality, often denoted as 'x'. This constant allows us to convert the ratios into actual angle measures.

Convex vs. Non-Convex Quadrilaterals

This is where things get interesting! The classification of a quadrilateral as convex or non-convex (also known as concave) depends on its interior angles. A convex quadrilateral is one where all interior angles are less than 180 degrees. Imagine drawing lines connecting any two points inside the quadrilateral – all those lines will also lie entirely within the quadrilateral. Think of a square or a rectangle. On the other hand, a non-convex quadrilateral has at least one interior angle greater than 180 degrees. This gives it a kind of “dent” or “cave” in its shape. If you draw a line connecting two points inside a non-convex quadrilateral, some parts of the line might fall outside the quadrilateral.

Solution: Scenario a) Angles Proportional to 1, 2, 3, 4

Alright, let's roll up our sleeves and tackle the first scenario. Here, the angles of our quadrilateral are proportional to the numbers 1, 2, 3, and 4. This means that we can represent the angles as x, 2x, 3x, and 4x, where 'x' is our constant of proportionality.

Step 1: Set up the Equation

We know that the sum of the interior angles in any quadrilateral is 360 degrees. So, we can set up the following equation:

x + 2x + 3x + 4x = 360

Step 2: Solve for x

Combine the terms on the left side of the equation:

10x = 360

Now, divide both sides by 10 to isolate 'x':

x = 36

Step 3: Calculate the Angles

Now that we've found the value of 'x', we can easily calculate each angle:

  • Angle 1: x = 36 degrees
  • Angle 2: 2x = 2 * 36 = 72 degrees
  • Angle 3: 3x = 3 * 36 = 108 degrees
  • Angle 4: 4x = 4 * 36 = 144 degrees

So, the angles of the quadrilateral in this scenario are 36°, 72°, 108°, and 144°.

Step 4: Determine Convexity

To determine whether this quadrilateral is convex or non-convex, we need to check if any of the angles are greater than 180 degrees. In this case, all angles (36°, 72°, 108°, and 144°) are less than 180 degrees. Therefore, the quadrilateral is convex. Think of it as a nicely shaped, well-behaved quadrilateral!

Solution: Scenario b) Angles Proportional to 1, 2, 2, 13

Now, let's move on to the second scenario, where the angles are proportional to 1, 2, 2, and 13. We'll follow a similar approach as before, but this time, we might encounter a different kind of quadrilateral.

Step 1: Set up the Equation

Again, we can represent the angles using the constant of proportionality 'x': x, 2x, 2x, and 13x. The sum of the interior angles is still 360 degrees, so we have:

x + 2x + 2x + 13x = 360

Step 2: Solve for x

Combine the terms on the left side:

18x = 360

Divide both sides by 18:

x = 20

Step 3: Calculate the Angles

Now we can find the measure of each angle:

  • Angle 1: x = 20 degrees
  • Angle 2: 2x = 2 * 20 = 40 degrees
  • Angle 3: 2x = 2 * 20 = 40 degrees
  • Angle 4: 13x = 13 * 20 = 260 degrees

The angles in this scenario are 20°, 40°, 40°, and a whopping 260°.

Step 4: Determine Convexity

Aha! This is where things get interesting. We have one angle that measures 260 degrees, which is significantly greater than 180 degrees. This immediately tells us that the quadrilateral is non-convex. Imagine a quadrilateral with one angle so large that it creates a
