In geometry, a directed line segment is a line segment with a specific direction. This means that the order of the endpoints matters. Partitioning a directed line segment involves dividing it into smaller segments with a given ratio. In this article, we will explore how to find the coordinates of a point that partitions a directed line segment into a specific ratio. We will delve into the concepts and formulas required to solve this type of problem, providing a comprehensive guide for understanding and applying these techniques. Our focus will be on a specific example, where we are given the endpoints of a directed line segment, $L(-6, 2)$ and $N(5, -3)$, and we aim to find the coordinates of point $M$ that partitions the segment in a particular ratio.

Understanding Directed Line Segments

A directed line segment is a line segment with a defined direction. Unlike a regular line segment, where the order of the endpoints doesn't matter, a directed line segment has a starting point and an ending point. This direction is crucial when partitioning the segment, as it determines the order in which we calculate the division. The direction is typically indicated by the order in which the endpoints are given. For instance, the directed line segment from point $L$ to point $N$ is different from the directed line segment from point $N$ to point $L$. In our case, we are considering the directed line segment from $L(-6, 2)$ to $N(5, -3)$, which means we start at $L$ and move towards $N$. Understanding this direction is the first step in accurately partitioning the segment. The concept of directed line segments is fundamental in various areas of mathematics, including vector geometry and coordinate geometry, where direction and magnitude play a significant role in defining geometric objects and transformations.

The Section Formula: The Key to Partitioning

The section formula is a fundamental tool in coordinate geometry that allows us to find the coordinates of a point that divides a line segment in a given ratio. This formula is particularly useful when dealing with directed line segments, as it takes into account the direction of the segment. The section formula can be applied both internally (when the point lies on the segment) and externally (when the point lies on the extension of the segment). In the context of partitioning a directed line segment, we are typically interested in the internal division. The section formula states that if a point $M(x, y)$ divides the line segment joining points $L(x_1, y_1)$ and $N(x_2, y_2)$ in the ratio $m:n$, then the coordinates of $M$ are given by:

x=mâ‹…x2+nâ‹…x1m+nx = \frac{m \cdot x_2 + n \cdot x_1}{m + n}

y=mâ‹…y2+nâ‹…y1m+ny = \frac{m \cdot y_2 + n \cdot y_1}{m + n}

This formula essentially calculates a weighted average of the coordinates of the endpoints, where the weights are determined by the ratio $m:n$. The ratio represents the proportional distances from point $L$ to point $M$ and from point $M$ to point $N$. Understanding and applying the section formula correctly is crucial for accurately finding the coordinates of the partitioning point. It allows us to break down the problem into manageable steps, calculating the $x$-coordinate and $y$-coordinate separately using the given ratio and endpoint coordinates.

Applying the Section Formula: A Step-by-Step Guide

To effectively use the section formula, it is essential to follow a systematic approach. Let's break down the application of the formula into clear steps. First, identify the coordinates of the endpoints of the directed line segment. In our case, we have $L(-6, 2)$ and $N(5, -3)$. Next, determine the ratio in which the segment is to be partitioned. Let's assume, for the sake of illustration, that we want to divide the segment in the ratio $2:3$. This means that the segment from $L$ to $M$ is two-fifths of the total length, and the segment from $M$ to $N$ is three-fifths of the total length. Now, we can apply the section formula. We substitute the coordinates of the endpoints and the ratio into the formula for the $x$-coordinate:

x=2⋅5+3⋅(−6)2+3=10−185=−85=−1.6x = \frac{2 \cdot 5 + 3 \cdot (-6)}{2 + 3} = \frac{10 - 18}{5} = \frac{-8}{5} = -1.6

Similarly, we substitute the values into the formula for the $y$-coordinate:

y=2⋅(−3)+3⋅22+3=−6+65=05=0y = \frac{2 \cdot (-3) + 3 \cdot 2}{2 + 3} = \frac{-6 + 6}{5} = \frac{0}{5} = 0

Therefore, the coordinates of point $M$ that partitions the directed line segment $LN$ in the ratio $2:3$ are $(-1.6, 0)$. By following these steps carefully, you can accurately apply the section formula to find the coordinates of any point that partitions a directed line segment in a given ratio. This methodical approach ensures that you correctly substitute the values and perform the calculations, leading to the correct result. The section formula is a powerful tool for solving a wide range of geometry problems involving the division of line segments.

Example: Finding the Coordinates of Point M

Let's consider the specific example given: the directed line segment from $L(-6, 2)$ to $N(5, -3)$. We need to find the coordinates of point $M$ that partitions this segment. However, the ratio in which the segment is partitioned is not explicitly given in the original problem statement. To proceed, we need to assume a ratio or introduce a variable to represent it. For the purpose of this example, let's assume that point $M$ partitions the segment in the ratio $r:1$, where $r$ is a variable. This means that the distance from $L$ to $M$ is $r$ times the distance from $M$ to $N$. Now, we can apply the section formula using this ratio. The $x$-coordinate of $M$ is given by:

x=r⋅5+1⋅(−6)r+1=5r−6r+1x = \frac{r \cdot 5 + 1 \cdot (-6)}{r + 1} = \frac{5r - 6}{r + 1}

And the $y$-coordinate of $M$ is given by:

y=r⋅(−3)+1⋅2r+1=−3r+2r+1y = \frac{r \cdot (-3) + 1 \cdot 2}{r + 1} = \frac{-3r + 2}{r + 1}

Thus, the coordinates of point $M$ are $\left(\frac{5r - 6}{r + 1}, \frac{-3r + 2}{r + 1}\right)$. Without a specific value for the ratio $r$, we cannot determine the exact numerical coordinates of $M$. However, this expression provides a general formula for the coordinates of $M$ in terms of the ratio $r$. If a specific ratio is given, we can simply substitute it into this formula to find the corresponding coordinates of $M$. For instance, if $r = 1$, which means $M$ is the midpoint of the segment, the coordinates of $M$ would be:

x=5(1)−61+1=−12=−0.5x = \frac{5(1) - 6}{1 + 1} = \frac{-1}{2} = -0.5

y=−3(1)+21+1=−12=−0.5y = \frac{-3(1) + 2}{1 + 1} = \frac{-1}{2} = -0.5

So, the midpoint would be $(-0.5, -0.5)$. This example illustrates how the section formula can be applied in a general case and how specific ratios can be used to find the exact coordinates of the partitioning point. Understanding the relationship between the ratio and the coordinates of the partitioning point is crucial for solving various geometry problems.

Special Case: The Midpoint Formula

A special case of the section formula is the midpoint formula. The midpoint of a line segment is the point that divides the segment into two equal parts, meaning the ratio of division is $1:1$. The midpoint formula is derived directly from the section formula by setting $m = n = 1$. If $L(x_1, y_1)$ and $N(x_2, y_2)$ are the endpoints of a line segment, then the coordinates of the midpoint $M$ are given by:

x=x1+x22x = \frac{x_1 + x_2}{2}

y=y1+y22y = \frac{y_1 + y_2}{2}

This formula simply calculates the average of the $x$-coordinates and the average of the $y$-coordinates of the endpoints. Applying this to our example, where $L(-6, 2)$ and $N(5, -3)$, the midpoint $M$ would have coordinates:

x=−6+52=−12=−0.5x = \frac{-6 + 5}{2} = \frac{-1}{2} = -0.5

y=2+(−3)2=−12=−0.5y = \frac{2 + (-3)}{2} = \frac{-1}{2} = -0.5

Thus, the midpoint of the directed line segment $LN$ is $(-0.5, -0.5)$, which confirms our previous calculation using the general section formula with a ratio of $1:1$. The midpoint formula is a convenient and frequently used tool in geometry, providing a quick way to find the center point of a line segment. It is a fundamental concept in various geometric constructions and proofs, and it is essential to have a solid understanding of its application. The midpoint formula is also closely related to other geometric concepts, such as the perpendicular bisector of a line segment, which passes through the midpoint and is perpendicular to the segment. Understanding the midpoint formula helps in visualizing and analyzing geometric figures and relationships more effectively.

Conclusion

Finding the coordinates of a point that partitions a directed line segment involves understanding the concept of directed line segments and applying the section formula. The section formula provides a powerful tool for dividing a line segment in a given ratio, taking into account the direction of the segment. By carefully substituting the coordinates of the endpoints and the ratio into the formula, we can accurately calculate the coordinates of the partitioning point. The midpoint formula, a special case of the section formula, simplifies the process of finding the midpoint of a line segment. These concepts and formulas are fundamental in coordinate geometry and have wide applications in various mathematical and practical problems. Mastering the techniques for partitioning directed line segments enhances our ability to analyze and solve geometric problems involving lines, segments, and ratios. The ability to partition a directed line segment is essential in fields such as computer graphics, engineering, and navigation, where precise positioning and division are critical. By understanding the underlying principles and applying the appropriate formulas, we can confidently tackle a wide range of problems involving the division of line segments.

In summary, the key to successfully partitioning a directed line segment lies in a clear understanding of the section formula and its application. By identifying the endpoints, determining the ratio, and carefully substituting the values into the formula, we can accurately find the coordinates of the partitioning point. The midpoint formula provides a convenient shortcut for the special case where the segment is divided into two equal parts. With practice and a solid grasp of these concepts, we can confidently solve a variety of problems involving directed line segments and their partitions. The knowledge and skills gained in this area are valuable tools for further exploration in geometry and related fields.
